BANSBACH
/
牽引式氣壓棒
產品說明
| Pull-in force: |
100-4000 N (depends on diameter piston rod/cylinder) | |
| Stroke: | 10-600 mm | |
| Diameter cylinder/pis ton rod: |
8/22, 10/28 and 14/40 | |
| Speed/ damping: |
The speed of gas traction spring with short construction is always fast and cannot be damped. A valve (undamped) is possible for this Type. | |
| Connecting parts: | You can find the right „connection“ for your gas spring here. | |
| Long type: | ||
| Pull-in force: | 50-2500 N (depends on diameter piston rod/cylinder) | |
| Stroke: | 10-200 mm | |
| Diameter cylinder/pis ton rod: |
6/19, 8/22, 10/28 and 14/40 | |
| Speed/ | Our gas springs are available with fast normal and slow extension speed. Regarding the damping, you can choose between normal, increased and no end damping, however, this becomes only efficient if the gas spring is mounted | |
| damping: | with the piston rod showing downwards. | |
| Connecting parts: | You can find the right „connection“ for your gas spring here | |
